| Place of Origin: | China |
| Brand Name: | HY |
| Certification: | CE ISO |
| Model Number: | 20211222007 |
| Minimum Order Quantity: | 5T |
|---|---|
| Price: | $2,560.00/tons 1-14 tons |
| Packaging Details: | Standard seaworthy export packing |
| Delivery Time: | 5-8work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 5000 Ton/Tons per Month |
| Standard: | Stainless Steel Galvanized Angle | Grade: | 304, 316, 316L, 201 |
|---|---|---|---|
| Processing Service: | Decoiling, Punching | Steel Grade: | 301L, 301, 310S, 316Ti, 316L, 316, 321, 410S, 314, 430, 309S, 304, 409L, 304L, 904L |
| Delivery Time: | 8-14 Days | Technique: | Cold Rolled Hot Rolled |
| Material: | 200 Series/300 Series/400series | Surface: | BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D |
| Material Mill: | Posco | Payment Terms: | 30%T/T Advance + 70% Balance |
| MOQ: | 10Ton | Port: | Qingdao |
| High Light: | Construction ss angle bar,2205 ss angle bar,Galvanized Stainless Steel Angle |
||
Mechanical properties of angle steel: (1) Inspection method: ① Tensile test method. Commonly used standard inspection methods are GB/T228-87, JISZ2201, JISZ2241, ASTMA370, ГОСТ1497, BS18, DIN50145, etc.; ② Bending test method. Commonly used standard inspection methods are GB/T232-88, JISZ2204, JISZ2248, ASTME290, ГОСТ14019, DIN50111, etc. (2) Performance indicators: The inspection items for evaluating the performance of angle steel are mainly tensile test and bending test. Indicators include yield point, tensile strength, elongation and bending qualification.
Weight calculation
Weight per meter=0.00785*(side width+side width-side thickness)*side thickness For example, 50*5 angle steel: (50+50-5)*5*0.00785=3.73 (this algorithm can only roughly calculate the angle steel weight)
Products Description
|
Item Name |
Stainless Steel Angle Bar |
|
|
Standard |
AISI,ASTM,BS,DIN,GB,JIS, etc |
|
|
Material |
A36,s235jr,S275jr,S355jr,st37-2,SS400,Q235,Q345, etc... |
|
|
Thickness |
3mm - 24mm |
|
|
Equal Angle |
Type: |
2#-20# |
|
Size: |
20-200MM |
|
|
Thickness |
3.0-24MM |
|
|
Weight |
0.597-71.168kg/M |
|
|
Unequal Angle |
Type |
2.5*1.6-20*12.5# |
|
Size |
25*16-200*125mm |
|
|
Long side |
20-200mm |
|
|
Short side |
|
|
|
Thickness |
3- 24mm |
|
|
Weight |
1.687-43.588kg/m |
|
|
Length |
1-12m or as customer request |
|
|
Surface |
Oil,Black, Galvanized, Painted |
|
|
Technique |
Hot rolled/Cold rolled/Galvnized |
|
|
Name |
Stainless Steel Channel |
|
Material |
201, 202, 301, 302, 304, 304L, 310S, 316, 316L, 321, 430, 430A, 309S, 2205, 2507, 2520, 430 , 410, 440, 904Lect, Or Customized |
|
Surface |
BA, 2B, 2D, 4K, 6K, 8K, NO.4, HL, SB, Embossed |
|
Thinckness |
0.3mm-60mm |
|
Widthness |
50mm~2000mm or customized |
|
Length |
1000mm~8000mm or customized |
|
Certifications |
ISO 9001 BV SGS |
|
Packing |
Industry standard packaging or according to client's requirement |
|
Brand |
TISCO,ZPSS,Baosteel,POSCO,LISCO,YUSCO,Ansteel, QPSS,JISCO,HXSCO, |
|
Payment terms |
30%T/T in advance, the balance against the B/L copy |
|
Delivery time |
Fast delievery in 7 days,up to order quantity |
About us
Wuxi Hongye New Material Co. LTD was engaged in steel and aluminum materials since 2008,located in Jinan city, China, which main products are:GI,GL,galvanized steel coil, galvalume steel coil, color coated steel coil (PPGI,PPGL),stainless steel, Carbon steel,tinplate,color coated aluminum coil, aluminum sheet, steel pipe,roofing sheet,cold rolled steel, etc. After years of development, the company has a strong production capacity, with a monthly output of 30,000 tons, ranking among the top five in the industry. Our products has the advantages of high precision, good finish and high material utilization. It has made up and solved the shortcomings of CNC machining, powder metallurgy, cold extrusion, dewaxing casting and so on. It is widely used in machinery, decoration, medical, electrical appliances, automobile industry, electric tools, electronic instruments, kitchens, furniture and other industries. We insist on providing customized service for the customers. Our products are exported to more than 80 countries and regions. Europe: France, Germany, Italy, Netherlands, Hungary, Spain, Portugal, Macedonia, Greece, Czech Republic. Latin America:Brazil, Mexico,Columbia,Panama, Guatemala, Peru, Chile, Argentina, etc. Southeast Asia: Vietnam, Thailand, Indonesia, Philippines, Cambodia, etc.
